T-Motor MN805-S 170KV
T-Motor MN805-S 170KV
T-Motor MN805-S 170KV
T-Motor MN805-S 170KV
T-Motor MN805-S 170KV

T-Motor MN805-S 170KV

Non-returnable
₹30,379.00
The T-Motor MN805-S 170KV is a heavy-load brushless motor designed for professional multirotor, VTOL, and fixed-wing UAVs. With a maximum thrust of 16kg and IP45 dust/water/anti-corrosion protection, it ensures reliable and stable performance for demanding tasks like aerial photography, mapping, and cargo delivery. Its advanced cooling guarantees long service life.
Choose Quantity
+ Add to Cart
Product Details
Features:

  • Heavy load motor, born for VTOL.
  • Max thrust up to 16kg.
  • Long service life (MTBF about 1000 hours).
  • Excellent centrifugal cooling performance (15% enhanced).
  • Anti-high temperature/Anti-overload protection.
  • IP45 dust-resistance, waterproof, and anti-corrosion.
  • Semi-closed design protects from debris.
  • Special alloy shaft, custom bearings (24mm large bearings).
  • Varnished wires, silicon steel sheet, magnet, and bell treated with anti-rust/anti-corrosion technology.
  • T-shape shaft secured with circlip and screw for safety.

Technical Specifications:

  • Motor Size: Φ89*44.4mm
  • Copper Wire: 220°C high temperature resistance: Level C
  • Stator: Imported silicon steel sheet; Anti-rust treatment; 150°C high temperature-resisting coatings
  • Coil Insulation Test: 500V
  • Configuration: 24N28P
  • Centrifugal Cooling Design: YES
  • Shaft Diameter: IN: 12mm, OUT: 8mm
  • Rotor Dynamic Balance Standard: ≤5Mg
  • Bearing: Imported 6901ZZ
  • Motor Dynamic Balance Standard: ≤10Mg
  • Magnet Level: 180°C high temperature resistance
  • IP: IP45
  • Lead Cable: 14AWG*150mm
  • KV: 170
  • Rated Voltage (Lipo): 6-12S
  • Idle Current(15V): 2.6A
  • ESC Recommendation: FLAME 100A 14S
  • Peak Current(180s): 83A
  • Propeller Recommendation: 26-27"
  • Max.Power(180s): 4000W
  • Motor Weight (incl. Cable): 625g
  • Internal Resistance: 28mΩ
  • Package Weight: 750g

Additional Details:

  • Manufacturer: T-Motor
  • Brand: T-Motor
  • Generic Name: UAV Motor || Drone Motor || Brushless Motor || Multirotor Motor || Professional Drone Motor || Heavy-Lift Motor || Waterproof Motor || Electric Motor || Outrunner Motor || Industrial Drone Motor
  • Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
  • Ideal For: Heavy-Load Multirotors (e.g., 30-40kg takeoff weight drones) || VTOL Aircraft || Fixed-Wing UAVs || Professional Aerial Photography Drones || Mapping & Surveying UAVs || Cargo Drones || Tethered Drones || Inspection Drones || Surveillance Drones || Custom Industrial UAV Builds || Commercial Drone Applications || All-Weather Drone Operations.

Package Details:

Includes:
  • 1 x T-Motor MN805-S 170KV Brushless Motor
  • 1 x Hardware pack (typically includes propeller adapter/nut and mounting screws)

Frequently Asked Questions:

Q1. What battery voltage range is recommended for the T-Motor MN805-S 170KV motor?
Ans. This motor is designed for high-voltage systems, operating optimally with 6-12S LiPo batteries, providing significant power and flexibility for heavy-load UAV applications.

Q2. What level of environmental protection does the T-Motor MN805-S 170KV motor offer for outdoor operations?
Ans. The MN805-S features an IP45 rating, meaning it is dust-resistant, waterproof against splashes, and has anti-corrosion treatment, ensuring high reliability in harsh outdoor and variable weather conditions.

Q3. What is the maximum thrust capability of the T-Motor MN805-S 170KV motor, and what propeller sizes are recommended?
Ans. This motor can deliver an impressive maximum thrust of up to 16kg (16000g), and it is recommended to use 26-27 inch propellers (e.g., G289.2, G3211) for optimal performance.
