SKYZONE SKY04O V2 FPV Goggles
₹44,729.00
Out of stock
SKYZONE SKY04O V2 FPV Goggles redefine the FPV experience with high-resolution 1024×768 OLED displays and a wide 38° FOV for immersive visuals. Built for both near- and far-sighted users with adjustable -6~+2 focus, these goggles feature dual 5.8GHz 48CH receivers with SteadyView technology for superior signal stability. Enjoy DVR functionality with H.264 encoding at 60FPS, support for 4:3 and 16:9 ratios, and expandability via a modular bay. Power options include DC 6.5–25.2V or USB 5V, housed in a lightweight 262g design. SKY04O is perfect for FPV enthusiasts seeking crystal-clear image quality and robust usability.
Product Details
Features
- 1024×768 OLED screen for vivid color and clarity
- Wide 38° FOV for immersive viewing
- Dual 5.8GHz 48CH SteadyView receiver modules
- Adjustable focus: -6 to +2 for vision correction
- Supports 4:3 and 16:9 aspect ratios
- 60FPS DVR recording with H.264 encoding
- Modular bay for receiver upgrades
- Multilingual support: 10 languages
- 3-axis head tracker (accelerometer + gyroscope)
Technical Specifications
- Model: SKY04O V2
- Screen: OLED
- Resolution: 1024 × 768
- Field of View (FOV): 38°
- Aspect Ratio: 4:3 / 16:9
- Interpupillary Distance (IPD): 58 ~ 71mm
- Focus Adjustment: -6 ~ +2
- Receiver: 5.8GHz 48CH
- Language Support: 10 languages
- Power Supply: DC 6.5 ~ 25.2V / USB 5V
- Power Consumption: 720mA @ 12V
- DVR Format: H.264, 60FPS, MOV, 6Mbps, supports SD card up to 128GB
- Head Tracker: 3-axis gyroscope + 3-axis accelerometer
- Antenna Connector: SMA
- Dimensions: 185 × 75 × 67mm
- Weight: 262g
Package Includes
- 1 × SKY04O FPV Goggles
- 1 × 5.8GHz Receiver Module
- 2 × Faceplates (wide and narrow)
- 2 × Sponge with Band
- 1 × Zipper Case
- 1 × Power Cable
- 1 × Head Tracker Cable
- 2 × 5.8GHz 2dBi Antennas
- 1 × Video/Audio Cable
- 1 × USB-C Cable
- 1 × User Manual
Additional Details
- Modular bay allows future upgrade of video receiver modules
- DVR functionality helps you analyze flights post-session
- USB-C support ensures modern connectivity
- Head tracking support for enhanced simulation control
- Lightweight build makes it suitable for long-duration usage
- Generic Name: OLED FPV Goggles || 5.8GHz Drone Goggles || SKYZONE FPV Headset || High-Resolution FPV Goggles || Adjustable Focus FPV Goggles || FPV Goggles with DVR || Dual-Antenna Drone Goggles
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
Frequently Asked Questions
Q1: Does this goggle support DVR recording?
Yes, it supports DVR with H.264 encoding at 60FPS and MOV format.
Q2: Can I use this with my prescription glasses?
No need—use the built-in adjustable focus range of -6 to +2.
Q3: What kind of batteries can power it?
It supports a wide voltage input from 6.5V to 25.2V or USB 5V.
