SIYI-A2 MINI GIMBLE CAMERA
₹13,999.00
Out of stock
The SIYI A2 Mini is a compact (85g) single-axis gimbal camera offering a 1080p Full HD experience with a 160° ultra-wide-angle lens. Featuring distortion correction, starlight FPV capabilities, and IP67 industrial protection, it delivers clear, stable, and immersive FPV footage. Ideal for agricultural drones, inspection, and FPV pilots seeking a rugged and efficient aerial view.
Product Details
Features:
- Ultra-wide angle 160° FOV lens.
- Full HD 1080p resolution (2MP sensor).
- Powerful distortion correction algorithm.
- Starlight FPV capability for low light.
- Industry-grade IP67 protection (Waterproof/Dustproof).
- Single-axis tilt gimbal for smooth vertical movement.
- Upside Down Mode for flexible mounting.
- Multiple control inputs (S.Bus, PWM, Ethernet UDP).
- Ethernet video output for digital transmission.
- Compact and lightweight design (85g).
Technical Specifications:
- Video Output Port: Ethernet
- Control Signal Input Port: S.Bus, PWM, Ethernet UDP
- Working Voltage: 12V
- Power Consumption: Average: 2 W, Summit: 12 W
- Working Temperature: -10°C ~ 50°C
- Dimension: 654350 mm
- Weight: 85 g
- Controllable Pitch Angle: -90° ~ 25°
- Camera FOV: Horizontal 160°
- Camera Image Sensor: 1/2.7 Inch, 2 MP effective resolution
- Android App: SIYI FPV App, SIYI QGroundControl App
Additional Details:
- Manufacturer: SIYI Technology
- Brand: SIYI
- Generic Name: Drone Gimbal Camera || UAV Camera || FPV Gimbal Camera || Wide Angle Camera || Drone Camera || Industrial Drone Camera || Waterproof Camera || Starlight Camera || Single Axis Gimbal || Drone Payload
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Agricultural Spraying Drones || FPV Drone Applications || Inspection Drones || Surveillance Drones || Mapping (overview FPV) || Custom Drone Builds || Pilots requiring wide and unobstructed views || Harsh Environment Operations || Training Drones || Robotics & UGV applications (requiring wide angle view).
Package Details:
Includes:
- 1 x SIYI A2 Mini Ultra Wide Angle FPV Gimbal Camera
Frequently Asked Questions:
Q1. What is the main advantage of the SIYI A2 Mini's ultra-wide-angle lens?
Ans. The 160° ultra-wide-angle lens provides an extensive view of the operational field, allowing the drone operator to have a clear sight without frequently adjusting the drone's attitude, which is especially useful for applications like agricultural spraying.
Q2. Does the SIYI A2 Mini gimbal camera have environmental protection?
Ans. Yes, it features an industry-grade IP67 protection rating, meaning it is waterproof and dustproof, making it highly reliable for operations in challenging and harsh outdoor environments.
Q3. How is the gimbal controlled on the SIYI A2 Mini?
Ans. The gimbal can be controlled in multiple ways: through SIYI's FPV App or QGC App on SIYI handheld ground stations (e.g., MK32, MK15), or via standard PWM / S.Bus signals from a remote controller connected to the air unit.
Overall
Model: A2 miniVideo Output Port: Ethernet
Control Signal Input Port: S.Bus, PWM, Ethernet UDP
Working Voltage: 12 V
Power Consumption:
- Average 2 W
- Summit 12 W
Working Temperature: -10 ~ 50 ℃
Dimension: 65*43*50 mm
Weight: 85 g
Gimbal
Controllable Pitch Angle: -90° ~ +25°
Camera
FOV: Horizontal 160°
Image Sensor: 1/2.7-inch CMOS, 2 MP effective resolution
