SEAGULL-IR CAMERA TRIGGERS
₹1,859.00 ₹7,399.00
The Seagull #IR is a compact (1g) infrared camera trigger for UAVs, enabling remote shutter control for a wide range of cameras including Sony, Nikon, Canon, and Olympus. It provides a simple, wireless, and vibration-free solution for aerial photography, mapping, and wildlife observation by converting standard R/C PWM signals to IR commands.
Choose Quantity
Product Details
Features:
- Infrared (IR) camera triggering.
- Compact and ultra-lightweight (1g).
- Supports picture (shutter release).
- Supports video record (Sony cameras only).
- Compatible with major camera brands (Sony, Nikon, Canon, Olympus).
- Controlled by standard R/C PWM servo signal.
- Works with most modern R/C radio systems.
- Integrates with popular flight controllers (Pixhawk, APM, DJI).
- Enables non-contact shutter activation.
- Ideal for hands-free, vibration-free photography.
Technical Specifications:
- Voltage: 3.5 – 5.5 volts ( 5 volts recommended, do NOT exceed 5.5V! )
- Current draw: 22.5mA MAX
- Input signal: Standard R/C PWM servo signal ( between 1000 – 2000uS )
- Dimensions: 23.5mm x 9.8mm x 4.4mm
- Weight: 1g ( ~4g with servo cable )
- supports: Pixhawk 1, Pixhawk 2.1, Pixracer, APM 2.6, APM 2.5, DJI Wookong, DJI A2, DJI A3 and R/C radio systems That interfaces with standard PWM signal (almost any radio system) and verious cameras
Additional Details:
- Manufacturer: Seagull
- Brand: Seagull
- Generic Name: Camera Trigger || Infrared Trigger || Drone Camera Remote || UAV Shutter Release || RC Camera Control || Camera Accessory || Aerial Photography Trigger || Remote Photography Device || Wireless Camera Trigger || Drone Component
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Aerial Photography || Geomapping || Agriculture Analysis || 3D Modeling || Wildlife Photography || Surveillance || Drone Operations || Remote Photography || UAV-mounted cameras || Stealth Photography.
Package Details:
Includes:
- 1 x Seagull #IR Camera Trigger
- 1 x Servo cable (30cm length)
Frequently Asked Questions:
Q1. What types of cameras are compatible with the Seagull #IR camera trigger?
Ans. The Seagull #IR is compatible with a wide range of cameras from brands like Sony, Nikon, Canon, and Olympus, provided they have an infrared receiver for remote triggering.
Q2. How is the Seagull #IR controlled on a drone?
Ans. It is controlled via a standard R/C PWM servo signal, which can come directly from your R/C receiver or from a compatible flight controller (like Pixhawk, APM, or DJI systems) for automated triggering.
Q3. Can the Seagull #IR be used to record video, or only take pictures?
Ans. The Seagull #IR supports both picture (shutter release) and video recording functionalities; however, the video recording feature is currently only supported by compatible Sony cameras.
