RADIOMASTER Ranger Micro 2.4GHZ ELRS RF Module
₹4,839.00
Out of stock
The RadioMaster Ranger Micro 2.4GHz ELRS RF Module is a compact and high-performance external module designed for compatible RC transmitters. It provides reliable, long-range ExpressLRS connectivity for your drones and RC models, enhancing control and telemetry capabilities. Perfect for pilots seeking superior signal integrity and responsiveness in a small form factor.
Product Details
Features:
- Built-in ExpressLRS Backpack
- High-efficiency cooling system
- Wifi and Bluetooth support
- Packet rates up to F-1000Hz
- T-antenna included
- With the Micro connector, support TX16S MKII and TX12 MKII radio
Technical Details:
- Item: Ranger Micro Module
- Regulatory Domain: ISM2400
- MCU: ESP32(main), ESP8285(aux,as ESP backpack)
- RF chip: SX1281IMLTRT
- Frequency Range: 2400 MHz - 2480 MHz
- Maximum packet rate: 500Hz/F-1000Hz (F-1000Hz mode requires EgdeTX 2.7.1 or later)
- Minimum receiver refresh rate: 25Hz
- Wifi Support: Yes
- Bluetooth support: Yes
- XT30 Power supply voltage: DC 6V - 16.8V
- Weight: 50g (with antenna) / 40.5g (without antenna)
- Dimension: 136*49*33mm (with T antenna) / 74*49*33mm (without antenna)
Additional Details:
- Manufacturer: RadioMaster
- Brand: RadioMaster
- Generic Name: RF Module, ELRS Module, Radio Module, Transmitter Module
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: RC drone pilots, FPV racers, long-range RC enthusiasts, hobbyists upgrading their radio systems.
Package Details:
- includes: 1 x 1 x RADIOMASTER Ranger Micro 2.4GHZ ELRS RF Module
Frequently Asked Questions:
Q1: What radios is the Ranger Micro compatible with?
Ans: The Ranger Micro is designed for radios with a Micro module bay, such as the RadioMaster Zorro and Boxer. It can also be used with full-size JR module bay radios like the TX16S using the included Micro module bay adapter.
Q2: What is the maximum output power of the Ranger Micro?
Ans: The maximum output power can go up to 1000mW, depending on the ExpressLRS firmware version and your specific regional regulations.
Q3: Does this module include an antenna?
Ans: Yes, the package typically includes both a T-Antenna and a Moxon Antenna for optimal performance in different scenarios.
