MFE 40A 12S ESC
The MFE 40A 12S ESC is a robust, high-voltage brushless electronic speed controller engineered for demanding industrial and agricultural drone applications. It supports 12S LiPo battery systems, providing a continuous 40A (60A peak) current. It is deeply tuned for the MFE 5015 KV160 motor, guaranteeing exceptionally smooth start-up, highly efficient power output, and the reliability needed for heavy-lift and long-endurance professional UAV missions.
Features :
- Supports high voltage 12S LiPo input.
- 40 Amps continuous, 60 Amps peak current.
- Deeply optimized for MFE 5015 KV160 motor.
- Smooth starting and efficient power output.
- Robust design for heavy-duty applications.
- Precise throttle control for stable flight.
- Excellent heat dissipation via design.
- Includes multiple protection features.
- High-quality 16AWG power and motor wires.
- Ideal for professional UAV operations.
Technical Specifications:
- Number of Battery Cells: 12S LiPo
- Continuous/Instantaneous (10s) Current: 40A/60A
- Power Cord: 16AWG 55cm
- Motor Wire: 16AWG 10cm
- Signal Cable: 30-core black and white double twisted pair 55cm
- Banana Head: 3.5mm Female Connector
- Cold Pressed Terminals: 0T2.5-4
- Weight: 53g
Additional Details:
- Manufacturer: Makeflyeasy (MFE)
- Brand: MFE (Makeflyeasy)
- Generic Name: Brushless Electronic Speed Controller || ESC || 12S ESC || High Voltage ESC || Industrial Drone ESC || Agricultural Drone ESC || Motor Controller || Speed Controller || UAV ESC || Heavy Duty ESC
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Agricultural Spraying Drones || Industrial Inspection Drones || Logistics & Delivery UAVs || Heavy-Lift Drones || Professional Mapping Drones || Long-Endurance UAVs || Makeflyeasy Fighter VTOL || Makeflyeasy Struggler VTOL || Custom Large Drone Builds || Surveillance Drones
Package Details:
- Includes: 1x MFE-40A 12S ESC
Frequently Asked Questions:
Q1. Is the MFE-40A 12S ESC compatible with any 12S brushless motor?
Ans. No, the MFE-40A 12S ESC is specifically and deeply optimized for Makeflyeasy's own 5015 KV160 motor. Using it with other motor models is not recommended by the manufacturer and carries significant risks such as starting jams, high current blocking, or even burning out the ESC. It's crucial to use it only with the specified MFE motors.
Q2. Does this MFE 12S ESC provide power for my flight controller or receiver?
Ans. No, the MFE-40A 12S ESC is an "OPTO" type, meaning it does not have a built-in Battery Eliminator Circuit (BEC). You will need a separate, dedicated high-voltage UBEC or a power distribution board with a BEC to provide regulated power (e.g., 5V or 12V) to your flight controller, receiver, and other low-voltage electronics.
Q3. What kind of drones or applications is the MFE-40A 12S ESC best suited for?
Ans. The MFE-40A 12S ESC is primarily designed for high-voltage, heavy-duty industrial and agricultural drone applications. Its 12S compatibility and specific optimization for powerful MFE motors make it ideal for large-scale multirotors, VTOL aircraft (like the Makeflyeasy Fighter or Struggler VTOL), and other professional UAVs that require robust, efficient, and reliable power systems for demanding missions.
