Mauch 080: Sensor Hub X2 / DF-13

Features :

• Connects two Mauch current/voltage sensors.




• Provides redundant telemetry data paths.




• Uses reliable DF-13 connectors.




• Simplifies wiring for complex setups.




• Centralizes sensor data collection.




• Ensures robust communication with flight controller.




• Compact and lightweight design.




• Essential for advanced power monitoring.




• Improves overall system reliability.




• Easy to install and configure.

Technical Specifications:

• Model: Mauch 080: Sensor Hub X2

• Input Ports: 2x Sensor inputs (specifically designed for Mauch PL-xxx or HS-xxx series current/voltage sensors)

• Output Port: 1x Output to Flight Controller (DF-13 connector, typically for connecting to a flight controller's analog or I2C port, depending on the sensor type and how the hub processes data. It is crucial to verify if this hub merely passes through or aggregates data via a specific protocol like I2C/UAVCAN when paired with a Mauch Power Module. Assuming direct pass-through or basic aggregation for analog sensors).

• Connectors: DF-13 connectors for all sensor inputs and flight controller output.

• Compatibility: Designed primarily for Mauch PL-series (e.g., PL-100, PL-200) or HS-series (e.g., HS-050, HS-100, HS-200) current/voltage sensors.

• Function: Enables connection of multiple sensors for redundant telemetry or multi-point power monitoring.

• Dimensions: 39mm x 31mm x 6mm

• Weight: Very lightweight 7g without cables

• Operating Voltage: Typically passive, powered by the flight controller's sensor port or the connected power module.

Additional Details:

• Manufacturer: Mauch Electronics (Mauch Electronics GmbH)

• Brand: Mauch

• Generic Name: Sensor Hub || Telemetry Hub || Current Sensor Hub || Voltage Sensor Hub || Power Sensor Hub || Drone Sensor Hub || Data Concentrator || DF-13 Hub || UAV Electronics Hub || Wiring Hub

• Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)

• Ideal For: Drones with Redundant Power Systems || Complex UAV Builds || Agricultural Drones || Industrial Inspection UAVs || Heavy-Lift Drones || Professional Cinematography UAVs || Custom Multi-Rotor Builds || Fixed-Wing UAVs with Dual Sensors || Critical Mission Drones || Drone Testing & Development

Package Details:

Includes:

• 1x Sensor Hub X2

• 2x Current sensor board: HS-050-LV or HV =   2x50A = 0-100A Total , HS-100-LV or HV = 2x100A = 0-200A Total , HS-200-LV or HV = 2x200A = 0-400A Total

• 1x 2-6S BEC or 4-16S HYB-BEC

Frequently Asked Questions:

Q1. What is the primary purpose of the Mauch Sensor Hub X2 with DF-13 connectors?

Ans. The primary purpose of the Mauch Sensor Hub X2 is to allow the connection of two separate Mauch current and/or voltage sensors (like the PL-xxx or HS-xxx series) to a single input on a flight controller. This is particularly useful for achieving redundant power monitoring, where two sensors provide data, or for monitoring current/voltage at two different points in a complex power system, feeding the data to the flight controller via its DF-13 interface.

Q2. How does using the Sensor Hub X2 improve the reliability of my drone's telemetry data?

Ans. By allowing two independent sensors to connect, the Sensor Hub X2 significantly improves telemetry reliability by providing redundancy. If one sensor were to fail or provide erroneous readings, the flight controller (if configured for it) could potentially switch to or compare data from the second sensor, ensuring continuous and accurate power monitoring. This is crucial for mission-critical industrial or commercial drone operations.

Q3. Is the Mauch Sensor Hub X2 compatible with non-Mauch brand current/voltage sensors?

Ans. The Mauch Sensor Hub X2 is specifically designed with the pinout and electrical characteristics to interface seamlessly with Mauch PL-series and HS-series current/voltage sensors, utilizing DF-13 connectors. While technically possible to adapt other sensors if their outputs match, it is highly recommended to use it with genuine Mauch sensors to ensure proper functionality, calibration, and reliable telemetry data for your drone.
