iMAX B6-AC B6AC Lipo NiMH RCBattery Balance Charger
₹3,375.00
The iMAX B6-AC B6AC Lipo NiMH RC Battery Balance Charger is a high-performance microprocessor-controlled charger and discharger designed for versatile battery management across RC models, drones, and robotics. Featuring a built-in AC power supply and individual cell balancing, it safely charges and maintains LiPo, Li-ion, LiFe, NiMH, NiCd, and Lead-Acid battery packs.
Choose Quantity
Product Details
Features :
- Microprocessor-controlled operation optimizing charging efficiency and safety for multiple battery chemistries.
- Built-in AC switching power supply allowing direct connection to 100V-240V wall outlets or an external 11V-18V DC source.
- Internal independent lithium cell balancer ensuring precise voltage equalization across multi-cell packs.
- Comprehensive safety features including Delta-peak sensitivity, capacity limits, processing time limits, and temperature monitoring.
- Multi-mode functionality supporting fast charge, balance charge, storage mode, and discharge cycles.
Technical Details :
- Product Name: iMAX B6-AC Lipo NiMH Battery Balance Charger
- SKU: GEN-CHRG-3107
- AC Input Voltage: 100V–240V (50/60Hz)
- DC Input Voltage: 11.0V–18.0V
- Circuit Power: Max. Charge Power: 80W | Max. Discharge Power: 10W
- Charge Current Range: 0.1A–6.0A
- Discharge Current Range: 0.1A–2.0A
- LiPo / Li-ion / LiFe Cell Count: 1 to 6 Series Cells
- NiMH / NiCd Cell Count: 1 to 15 Cells
- Lead-Acid (Pb) Battery Voltage: 2V–20V
- Display: Backlit LCD Screen
Additional Details:
Manufacturer: Generic / OEM
Brand: iMAX
Generic Name: Digital Battery Balance Charger
Sold By: UAV Marketplace
Ideal For: FPV drone flight batteries, RC car packs, transmitter batteries, workshop maintenance, and field charging
Package Details:
1x iMAX B6-AC Charger Unit, 1x AC Power Cable, 1x DC Input Cable with Alligator Clips, 1x Multi-Adapter Charging Cable Set, 1x Instruction Manual
FAQs:
Q1) Can this charger be powered directly from standard household AC power sockets in India?
Ans: Yes, it features a built-in AC power supply supporting 100V–240V, allowing direct plug-in to standard wall outlets across India.
Q2) What battery chemistries and cell counts are supported by the iMAX B6-AC?
Ans: It supports 1S to 6S LiPo, Li-ion, and LiFe batteries, 1 to 15 cell NiMH/NiCd packs, and 2V–20V Lead-Acid (Pb) batteries.
Q3) Does the charger perform individual cell balancing for lithium battery packs?
Ans: Yes, it includes a built-in independent cell balancer that monitors and balances each cell individually during lithium charge cycles.
Q4) Can it be powered from a 12V field battery or car power outlet?
Ans: Yes, it includes a DC input port compatible with 11V–18V DC power sources such as field batteries or power supplies.
Q5) What is the maximum charge power and current output?
Ans: It delivers up to 80W of charge power with an adjustable charge current ranging from 0.1A to 6.0A.
