HOBBYWING X11 Plus with 4311 Propeller cw+ccw
The COMBO-X Rotor Pro-X11 Plus brushless power system is designed for plant protection and is suitable for uniaxial loads ranging from 15 to 18 kg. It features a maximum pulling force of 37 kg and is equipped with 50mm carbon fiber tube arms. The system has an IPX7 waterproof rating, making it resistant to rainwater, pesticides, salt spray, high temperatures, sand, dust , impact , mud , and soil.
Features:
- Built-in fault storage function for quick error analysis using the Hobbywing DataLink box.
- Multiple Intelligent Protection V2.0 for fast response to overcurrent and stall conditions within 270ms.
- IPX6 waterproof protection with fully sealed ESC for enhanced corrosion and rust resistance.
- Upgraded heat dissipation structure ensures better cooling and longer component life.
- Higher thrust up to 37kg and improved system efficiency compared to X11-18S.
- Optimized for low voltage and high power applications to achieve longer flight time.
- Equipped with power-on self-test, voltage abnormal, current overload, and stall protection.
Specification:
- Max Thrust37kg/rotor(54V, Sea Level)
- Recommended Takeoff Weight15-18kg/rotor(54V, Sea Level)
- Recommended Battery12-14S(LiPo)
- Operating Temperature0~50℃
- Total Weight2490g
- Ingress ProtectionIPX6
- Rated power input2500W
- Rated power output2130W
Motor
- KV Rating85rpm/V
- Stator Size111*18mm
- Powertrain Arm Tube Outer Diameter50mm
- BearingBearings imported from Japan
ESC
- Recommended LiPo Battery12-14S(LiPo)
- PWM Input Signal Level3.3V/5V
- Throttle Signal Frequency50-500Hz
- Operating Pulse Width1050-1950-us(Fixed or cannot be Programmed)
- Max. Input Voltage61V
- Max. Input Current (Short duration)150A(With/ Good Heat Dissipation)
- BECNo
Propeller
- Diameter Pitch43*11
Additional Details
- Manufacturer: Hobbywing
- Brand: XRotor
- Generic Names: Drone Motor Combo, UAV Propulsion System, Integrated Power System, Brushless Motor ESC Propeller Set
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Agricultural Spraying Drones ($\text{UAV}$s with approx. 30L capacity), Heavy-Lift Multirotors, Industrial Inspection Drones, Professional Drone Builders.
Package Include
- 1 * HOBBYWING X11 Plus with 4311 Propeller cw+ccw
Frequently Asked Questions
Q1: What size drone is the X11 Plus system best suited for?
ANS: It is optimally suited for large agricultural drones, particularly those with a water load capacity up to approximately 30 liters, supporting a takeoff weight of 15−18kg per rotor.
Q2: Does this system require a separate Electronic Speed Controller (ESC)?
ANS: No, the X11 Plus is an integrated propulsion system, meaning the brushless motor and the ESC are combined into a single, sealed unit for simplicity and enhanced protection.
Q3: What is the significance of the IPX6/IPX7 rating for this product?
ANS: The high IP rating means the system is fully sealed and highly resistant to water, dust, and corrosion, which is essential for $\text{UAV}$s that operate with liquid pesticides and in harsh outdoor environments.
