Made in India Flameback 4006 kv320 BLDC Motor
Non-returnable
₹9,399.00
Out of stock
The Flameback 4006 KV320 BLDC Motor is engineered for UAV applications that demand a balance of thrust, stability, and efficiency. Delivering over 2 kg of thrust at just 70 g weight, this motor supports 4-6S LiPo batteries and provides up to 350 W continuous power (300s). With its 18N24P configuration and unique finned design, it ensures excellent thermal management, smooth flight dynamics, and dependable performance in demanding environments.
Product Details
Features:
- Optimized Power-to-Weight Ratio: Generates over 2 kg thrust with only 70 g weight, enabling efficient lift for medium-lift UAVs.
- Advanced Thermal Design: Integrated finned housing ensures superior heat dissipation for consistent performance under extended flights.
- Rotor Balance Technology: Precision flux rings reduce inertia and vibration, delivering smoother and more stable flight control.
- Rugged Construction: High-strength build withstands demanding operating conditions without compromising efficiency.
- Environmental Protection: Sealed against dust and moisture ingress for reliable outdoor operation.
- Corrosion-Resistant Stator: Engineered for durability in humid and coastal climates.
- Shock and Impact Resilience: Robust structure tolerates hard landings and handling stress.
- Seamless Integration: Recommended with Flameback 45A 6S ESC and 14×4.8 / 15×5.5 propellers for optimal system performance.
Specification:
- Item Type: Drone motor
- Model Type: BLDC Motor
- Motor KV (RPM/V): 320
- Motor Type: Brushless Motor
- Shaft Diameter (mm): 4
- Max. Power (W) 350
- Maximum Thrust (gm) 2170
- Current Rating (A): 18
- Wire Gauge 18 AWG
- Stator Height 6mm
- Stator Diameter 40mm
- Configuration: 18N24P
- Compatible Prop (inch): 14 x 4.8, 15 x 5.5
- Compatible LiPo Batteries: 4S to 6S
- Operating Temperature (°C): -20 - 125°C
- Length (mm): 45.5
- Width (mm): 32
- Weight (g): 72
- Shipping Weight 0.163 kg
- Shipping Dimensions 11.5 × 7 × 6 cm
Additional Details:
- Manufacturer: Flameback
- Brand: Flameback
- Generic Name: BLDC Motor, Brushless Motor, Low KV Drone Motor, Endurance UAV Motor, High-Efficiency Outrunner, Multi-rotor Motor, Medium-Lift Motor.
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Medium-Lift Quadcopters, Mapping/Survey Drones, Long-Endurance Surveillance UAVs, Delivery Drones, Professional Cinematic Platforms, Industrial Inspection Drones.
Package Details
- Include: 1 x Made in India Flameback 4006 kv320 BLDC Motor
Warranty:
- This product is covered by a 12-month standard supplier warranty from the date of delivery, limited to manufacturing defects only. Replacement will be provided in such cases.
- Please note, the warranty will be void if the product is misused, tampered with, exposed to static discharge, accident, fire, water, or chemicals, or if it has been soldered, modified, or altered in any way.
Frequently Asked Questions:
Q1: What is the maximum battery voltage this 4006 KV320 motor supports?
ANS: The motor is designed to operate efficiently with 4S up to 6S LiPo batteries, making it suitable for high-voltage systems that maximize flight duration.
Q2: Why is a low KV rating (320) preferred for this motor size?
ANS: The low 320 KV is ideal for larger, slower-turning propellers (14-15 inches), which generate high thrust and achieve maximum efficiency, crucial for long-endurance and payload-carrying drones.
Q3: What size ESC is recommended to pair with the Flameback 4006 KV320 motor?
ANS: Given its maximum continuous current of 18A, a reliable 30A to 45A 6S-compatible ESC is recommended to ensure a safe overhead and optimal system performance.
