GEPRC GEP MK5 PRO Frame Kit
₹6,509.00 ₹12,599.00
The GEPRC GEP MK5 PRO Frame Kit is a high-performance, durable frame designed for freestyle FPV quadcopters. Featuring a squashed X arm design and aluminum alloy side plates, it offers excellent strength, reduced weight, and superior vibration dampening for stable flight and clear footage. It supports various FPV systems and action cameras, making it ideal for pilots seeking a robust and versatile freestyle platform.
Choose Quantity
Product Details
Features:
- Aluminum alloy side plates not only look stunning, but reduce weight and add more endurance.
- Developed specifically for freestyle with squashed X arm design.
- The installation hole of VTX is compatible with DJI Air Unit and VISTA, while maintaining the 30.5*30.5 analog VTX installation hole.
- Support the installation of 19-20mm width lens,you can directly install DJI original lens.
- Unique shock absorbing structure design, less vibrations and resonance.
- Specially designed independent capacitor and buzzer compartment for better performance and shaking reduction.
- Compatibility motor hole design, support the installation of 16x16mm and 19x19mm motors.
- Designed two different 3D printed parts bases, which can be installed with GP camera ,Naked camera GP8, Insta 360 GO2 and Caddx Peanut cameras,shooting is stable and clear. (Pro version comes with delivery)
- MARK5 frame kit is ideal for freestyle flying and bando-bashing resistant.
Technical Details:
- Model: GEP-MK5
- Motor to motor: 225mm
- Top plate: 2.5mm
- Bottom plate: 2.5mm
- Arm plate: 5.0mm
- FC mounting holes: 30.5mm x 30.5mm
- VTX mounting holes: 30.5mm x 30.5mm / 20mm x 20mm
- Motor mounting holes: 16mm x 16mm / 19mm x 19mm
- Camera installation space: 19-20mm
- Suitable propeller size: 5″propeller
- Dimension: 214mm x 168mm x 42mm
- Weight: 130.0g
Additional Details:
- Manufacturer: GEPRC
- Brand: GEPRC
- Generic Name: FPV Drone Frame, Quadcopter Frame, Freestyle Frame, Carbon Fiber Frame Kit, Racing Drone Frame
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: FPV Freestyle Flying, Racing, Drone Building, Aerial Filming (with action camera integration)
Package Details:
includes:
- 1 x MARK5 Frame Kits
- 1 x Battery strap M15x250mm
- 2 x Battery strap M20x220mm
- 2 x Battery Silicone Pads
- 1 x Set of 3D printings
- 2 x Action camera mount holder
- 1 x Set of screws
- 1 x Set of screwdrivers
- 1 x Antenna fixed tube
Frequently Asked Questions:
Q1. Is the GEPRC GEP MK5 PRO Frame compatible with DJI O3 Air Unit?
Ans: Yes, the GEPRC GEP MK5 PRO Frame is designed with mounting holes and includes 3D printed parts to accommodate the DJI O3 Air Unit, Caddx Vista, and analog VTX systems.
Q2. What action cameras can I mount on this frame?
Ans: The Pro version of the GEPRC GEP MK5 PRO Frame Kit includes two different 3D printed mounts that support a range of action cameras, including GoPro, Naked GoPro 8/10, Insta360 GO2, and Caddx Peanut cameras.
Q3. Is this frame durable enough for aggressive freestyle flying?
Ans: Absolutely. The GEPRC GEP MK5 PRO Frame features a robust 3K carbon fiber construction, 5.0mm thick arms, and durable aluminum alloy side plates, making it highly resistant to crashes and ideal for demanding freestyle and "bando-bashing."
