Made in India Electronic speed controller 45A 3-6S
Non-returnable
₹5,999.00
Out of stock
The Flameback 45A 3-6S ESC is engineered for high-performance drone applications, delivering reliable and efficient power control. With a continuous current of 45A and a burst capacity of 50A, it ensures smooth throttle response and stable flight performance. Supporting a wide range of protocols such as PWM, Oneshot125, Oneshot42, Multishot, and DSHOT (150/300/600), this ESC offers maximum versatility for advanced UAV setups.
Product Details
Features
- 45A continuous current, 50A burst capacity for demanding operations.
- Wide input range: Supports 3-6S LiPo batteries (11.1–22.2 V).
- Full NMOS design with dedicated MOSFET driver for efficiency.
- Rubycon low ESR capacitor ensures stable, noise-free operation.
- Advanced MOSFET package delivers lower heat generation and strong reliability.
- Operating temperature -20 °C to 125 °C; peak ESC temperature up to 140 °C.
- Built-in protections: overcurrent, undervoltage, overvoltage & thermal shutdown.
- IP56 rated- resistant to dust, splashes, and harsh environments.
- Multi-protocol support: PWM, Oneshot125, Oneshot42, Multishot, DSHOT150/300/600.
- Lightweight design (19.5 g) with compact dimensions 45 × 27.5 × 10.8 mm.
Specification
- ESC: Motor Configuration: 1:1
- Internal BEC: No
- Voltage rating: 3s - 6s LiPo (9.6 - 19.2V)
- Current rating: Continuous: 45A ,Burst: 50A
- Signal Frequency: 50 Hz - 500 Hz
- Product Dimensions (incl. Input capacitor & heat shrinkwrap, excl. Power & signal wires): 45 x 27.5 x 10.85 mm
- Weight: 19.55g, excl. input capacitor & input power wires
- Ambient Temperature: -20- 125°C
- Supported protocols (control signal from flight controller to ESC): PWM, Oneshot125, Oneshot42, Multishot, DSHOT150, DSHOT300, DSHOT600
- Programming / firmware upgrade / change internal parameters: FC Passthrough via signal wires
- Reports / documentation available: PCB inspection report
- RoHS compliance report
- Impedance control report
- Shipping Weight: 26 g
Additional Details:
Q2: What size drone or motor is the 45A rating suitable for?
ANS: It is typically suitable for most 5-inch FPV racing drones (especially with 4S-6S LiPo) or mid-sized fixed-wing RC aircraft requiring up to 45A continuous current per motor.
Q3: Which firmware and protocols does this ESC support for configuration?
ANS: The ESC usually runs on proprietary or industry-standard firmware like BLHeli_S/32, supporting high-speed digital protocols such as DShot600, Multishot, and Oneshot125 for precise throttle response.
- Manufacturer: Flameback Tech
- Brand: Flameback
- Generic Name: Electronic Speed Controller (ESC), Brushless ESC, Motor Controller, UAV ESC, Speed Regulator, Drone ESC.
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: RC Airplanes, FPV Racing Drones (5-inch class and larger), Quadcopters, Fixed-Wing UAVs, DIY Drone Builders, Robotics Projects
Package Details
- Include: 1 x Made in India Electronic speed controller 45A 3-6S
Warranty:
- This product is covered by a 12-month standard supplier warranty from the date of delivery, limited to manufacturing defects only. Replacement will be provided in such cases.
- Please note, the warranty will be void if the product is misused, tampered with, exposed to static discharge, accident, fire, water, or chemicals, or if it has been soldered, modified, or altered in any way.
Frequently Asked Questions:
Q1: Does this ESC include a BEC (Battery Eliminator Circuit)?
ANS: No, this is an OPTO-type ESC and does not have a built-in BEC. A separate UBEC or a Flight Controller with a BEC is required to power your receiver and flight controller.
ANS: No, this is an OPTO-type ESC and does not have a built-in BEC. A separate UBEC or a Flight Controller with a BEC is required to power your receiver and flight controller.
Q2: What size drone or motor is the 45A rating suitable for?
ANS: It is typically suitable for most 5-inch FPV racing drones (especially with 4S-6S LiPo) or mid-sized fixed-wing RC aircraft requiring up to 45A continuous current per motor.
Q3: Which firmware and protocols does this ESC support for configuration?
ANS: The ESC usually runs on proprietary or industry-standard firmware like BLHeli_S/32, supporting high-speed digital protocols such as DShot600, Multishot, and Oneshot125 for precise throttle response.
