MADE IN INDIA DGCA Type Certified FIA QD10 Agriculture Drone 10L(Standard Pack)
Non-returnable
₹500,000.00 ₹550,000.00
- Brand - Fuselage Innovation
- Payload - 10L
- Weight - 25Kg
Choose Quantity
Product Details
Main Feature :
- Flight Time - 25 Minutes
- Payload - 10L
- Weight - 25Kg
- Category - Small
- Power - 4KW
Frame Parameters :
- Diagonal Wheelbase - 2140MM
- Dimensions - 655*515*630mm ( arms & propeller folded)
1695*1795*630mm (arms & propeller unfolded)
Configuration :
- Type - Multirotor
- Configuration - Quadcopter
Flight Characteristics :
- Maximum altitude - 50 feet
Propulsion System :
- Stator Size - 100x10mm
- KV data - 100 rpm/v
- Pull force - 13.5 kg/rotor
- Type of rotor - BLDC
- number of rotor - 4
Propeller :
- Diameter Pitch - 30*9 inch
- Propeller Weight - 90g
ESC :
- Maximum Current - 100A
- Maximum Voltage - 44.4V (12S Lipo)
Flight Control System :
- Hovering Accuracy - +1m on a horizontal direction
- Max yaw Speed - 150 Degree / S
- Max Vertical Speed - 6m / s
- Temperature - 10 to 60 Degree centigrate
- Collision Avoidance System - Optional
Spray Tank :
- Tank Volume - 10 Litre
- Tank Weight - 0.9 kg
Spraying System :
- Pressure Nozzle - Single nozzle*4
- Pump Flow - 8L/minute
- Working Voltage - 44.4v
- Sprayinng Width - 4-6m
Power Battery :
- Voltage - 44.4v 12s
- Capacity - 16000mAh
- Weight - 3.6kg
- Size - 170*110*236mm
- Charging Plug - XT90 socket
- Magnifying Power - 25C
Remote Control Specification :
- Weight - 490g (Tx) * 26g (Rx) * 15.6g (camera)
- Channel - 12
- Battery Capacity - 4000mAh
- Endurance - 25hrs
- Frequency - 2.400GHz to 2.4833GHz
- Communication - FHSS
- Distance - 500Meters (video/data)
Mini Camera :
- Resolution - 720p@30
- Size - 30.2 x 29.8 x 26.8
- Voltage - 5V
- Temperature - -10 to +40 Degree Centigrate
Dual Charger :
- Input Voltage - 100-240V
- Output Power - 1080w(540w x 2) Discharging Power 50w x 2
- Charging Range - 1.0 - 20.0A x 2 Balance Current 1.2A Max
- Battery Type - Lipo/Lihv Battery Cell Count 6s x 2
- Charging modes - Fast Charge/balance charge/storage
- Size - 272 x 202 x 118 mm
Package Includes :
- 1 x 10 Liter Drone
- 1 x Transmitter & Camera 1 x Nozzle Pump System 1 x Batteries(pair)
- 1 x Dual Charger
- 1 × Tool Kit
