KST DS589MG V8.0 Mini Digital HV Metal Gear Servo 9.2Kgf.cm 0.08sec

Features:

• High-speed digital servo for rapid response.




• High-voltage (HV) compatibility for direct 2S LiPo use.




• Miniature size, ideal for tight spaces.




• All-metal gears for maximum strength and durability.




• Coreless motor for fast, smooth operation.




• High torque output for demanding applications.




• Exceptional centering accuracy and precision.




• Low power consumption.




• Designed for fixed-wing and VTOL control surfaces.




• Highly durable and shock-resistant.

Technical Specifications:

• Model: KST DS589MG V8.0

• Rated Voltage: DC7.4V

• Voltage Range: DC6.0V-8.4V

• Stalling Torque: 6.5Kgf.cm@6.0V, 8.0Kgf.cm@7.4V, 9.2Kgf.cm@8.4V

• No-load Speed: 0.10sec/60°@6.0V, 0.09sec/60°@7.4V, 0.08sec/60°@8.4V

• Working Frequency: 1520μs/333Hz

• Default Travel Angle: ±60°=120° Total

• Temperature Range: -20℃……+65℃

• Soft Start: Programmable

• Programmable: Yes

• Case Material: Aluminum Alloy

• Motor Type: Coreless DC Motor

• Gear Set Material: Hardened Steel

• Position Sensor: Potentiometer

• Case Dimensions: 35.5mm*15mm*32.5mm±0.2mm

• Weight: 40g±10%

Additional Details:

• Manufacturer: KST Servos

• Brand: KST

• Generic Name: Digital Servo || Mini Servo || HV Servo || Metal Gear Servo || High-Torque Servo || FPV Part || RC Servo || Drone Motor || Flight Control Component || UAV Actuator

• Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)

• Ideal For: FPV Racing Drones || Fixed-Wing UAVs || RC Gliders || VTOL Drones || Drone Builders || Robotics Projects || UAV Enthusiasts || Aerial Cinematography || Professional RC Models || Custom Drone Builds

Package Details:

• Includes:

  • 1x KST DS589MG V8.0 Mini Digital HV Metal Gear Servo

  • 1x Set of servo horns and mounting screws

Frequently Asked Questions:

Q1. What does "HV" mean on this servo?

Ans. "HV" stands for High Voltage. This means the servo is designed to be powered directly by a 2S LiPo battery (8.4V when fully charged) without the need for a separate voltage regulator. This simplifies wiring and provides a performance boost in terms of speed and torque.

Q2. Is this servo suitable for a high-speed application?

Ans. Yes, with a speed of just 0.08 seconds per 60 degrees, this is an extremely fast servo. Its coreless motor and digital control provide rapid, precise movements, making it an excellent choice for applications like FPV drone ailerons, wings, or any control surface that requires lightning-fast response.

Q3. What is the purpose of the metal gears?

Ans. The all-metal gears are designed for superior durability and strength. In high-stress or crash-prone environments, metal gears are much more resistant to stripping and breaking compared to plastic gears, ensuring a longer lifespan and more reliable performance under demanding conditions.
