AMASS AS150U Connector
Non-returnable
₹1,999.00 - ₹7,499.00
The AMASS AS150U Connector is a heavy-duty, anti-spark solution for high-voltage and high-current RC battery connections. Its integrated resistor prevents damaging sparks during initial connection, protecting your electronics from voltage spikes. Ideal for large drones, electric vehicles, and high-power setups requiring maximum safety and reliability.
Type
Nos
Product Details
Features
- Integrated anti-spark resistor prevents damage.
- Handles extremely high voltage and current.
- Gold-plated contacts for superior conductivity.
- Durable, high-temperature nylon housing.
- Ensures safe initial power connection.
- Ideal for large batteries and powerful systems.
- Robust design for demanding applications.
- Prevents voltage spikes and component wear.
- Easy to solder for secure connections.
- Provides ultimate power transfer reliability.
Technical Details
- Connector Type: AS150U (Male/Female pairs)
- Product Color: Yellow
- Current Rating: 70A Continuous (Peak: 140A)
- Feature: Integrated anti-spark resistor (on male connector)
- Recommended Wire Gauge: 8AWG to 6AWG (for direct soldering)
- Contact resistance: 0.40 m ohm
- Rated voltage: DC 500V
- Flame Retardant Rating: UL94 V0
- Recommended use: battery
- Metal Material: Copper Plating
- Recommended wire gauge: 8 AWG
- Insulation Material: PA6
- Operating Temperature: – 20 ~ 60
- Recommended usage time: 1000 times
- Waterproof rating: IP67
Additional Details
- Manufacturer: AMASS Electronics Co., Ltd.
- Brand: AMASS
- Generic Name: Anti-Spark Connector, High Voltage Connector, Large Current Plug, Heavy Duty Battery Connector, AS150 Plug
- Sold By: UAV Marketplace (an authorized seller of drone gear and accessories)
- Ideal For: Large FPV drones, electric longboards/skateboards, high-power RC cars/boats/planes, industrial drones, robotics, electric vehicles, any application requiring safe and reliable high-voltage/high-current connections.
Package Details
- Includes: 2pair/5pair Amass AS150U Male and Female Connector
Frequently Asked Questions
Q1. What is the primary benefit of an "anti-spark" connector like the AS150U?
Ans - The primary benefit is the integrated resistor in the male connector, which creates a temporary current path during initial connection. This prevents the large, damaging spark that typically occurs when connecting high-voltage, high-capacity batteries, protecting your electronics and connector lifespan.
Q2. What current and voltage levels is the AS150U designed for?
Ans - The AMASS AS150U is a heavy-duty connector designed for very high currents, typically rated for 150A continuous (with peaks over 200A), and can handle high voltages, commonly up to 14S LiPo batteries, making it suitable for powerful systems.
Q3. Is the AS150U compatible with other AMASS connectors like XT90?
Ans - No, the AS150U has a unique, larger pin configuration and is not compatible with XT90, XT60, or other smaller AMASS connectors. It is designed for significantly higher power levels and requires mating with another AS150U connector.
