The Cube Orange+ Standard Set Basics

23.08.24 12:30 PM By Akshay Joshi

CUBE+

HARDWARE SPECIFICATION

Main Processor
 STM32H757 Dual Core M7 + M4
 Coprocessor STM32F100
 Supported RC Signals PPM/SBUS/DSM
 Power Redundancy Triple redundancy
 Sensors
 Triple IMU System
 Sensors Details IMU1(Isolated) ICM42688
IMU3(Fixed) ICM20649 or ICM45686
MS5611 x 2(Baro)
 Supported FirmwareArdupilot, PX4, and Hionos DO-178C

 Supported Vehicle Types Fixed-wing plane
Multicopter
Helicopter
VTOL-plane
VTOL-plane Rover/boat/submarine

SPECIFICATION


SPECIFICATION

 Weight 73g
 Chassis MaterialCNC Aluminum Alloy(cube)+ABS Molding(Carrier Board)
 Size
cube 38.4x38.4x22mm
Carrier Board 94.5x44.3x17.3mm

 Operating temperature10~+55° IMU with temperature control
 PWM I/Os14
 Mavlink serial interface 4
 Number of GPS supported 2
 Debug interface2
 I2C interface 2
 CAN interface 2
Features






Supports multiple modes such as Loiter, Altitude Hold, AUTO(With Waypoints), Guide mode, etc

Supports Mission Planner and QGroundControl ground control stations
Built-in flight logging.

       Extensibility


Supports companion computers such as NVIDIA, Raspberry Pi,etc

Supports OSD


Protection Function


Smart RTL
battery low protection
Geo-Fencing
RC signal protection
